SMB-1001
Features
- Instant CPR release, degree show function at bedside rail.
- Bed High-Low, head (back rest) articulation, knee (foot rest) articulation
- Auto contour (head & knee together moving function)
- Trendelenburg and reverse trendelenburg with controls on both sides and the handset
- Lateral Tilt Position
- 10″ LED Screen for Nurse Control & Hand remote for patient
- 4-position I.V pole mounts.
- Abs Detachable Headboard and footboard
- Zero transfer gap retracting side rails for easy patient transfer, long and short bedside rails.
- One button control for trendelenburg, emergency service, be free from the bed, sitting position
Dimensions
Size: 2170*1180*700-1009mm
Angle of back section: 0~75°(±5°)
Angle of leg section: 0~45°(±5°)
Lateral Tilt: 0~ 16°
Trendelenburg and reverse Trendelenburg:0~13±2°
Adjustable height: 700-1090 mm”
Angle of back section: 0~75°(±5°)
Angle of leg section: 0~45°(±5°)
Lateral Tilt: 0~ 16°
Trendelenburg and reverse Trendelenburg:0~13±2°
Adjustable height: 700-1090 mm”
Accessories
- I.V. pole
- X-RAY Backrest
- Hand Remote
- 10″ LED Screen Control.
